HOWO 4×2 5T-20T Closed Box Truck
Load Capacity: 2T – 20T
Cargo Compartment Dimensions: 3.8m×1.8m×1.8m – 9.6m×2.4m×2.5m
Drive Type: 4×2, 4×4, 6×4, 8×4
Engine Power: 85HP – 380HP
Fuel Consumption: 8L/100km – 25L/100km
Tire Specification: 7.00R16、7.50R16、9.00R20、11.00R20
Chassis Brand: HOWO / FOTON / DONGFENG / FAW / SHACMAN / ISUZU
Emission Standard: Euro 2/3/4/5/6
Category:Box Truck
Introduction
Box Truck also known as Cargo Van, Closed Truck, or Dry Van, this Suizhou-manufactured vehicle is a cornerstone of efficient transportation. Designed with a fully enclosed cargo compartment, it excels in protecting goods from dust, moisture, and harsh weather.
Ideal for urban distribution, intercity freight, and long-haul transport, it handles diverse loads: construction materials, agricultural produce, consumer goods, and packaged cargo. Key advantages include customizable load capacities, durable bodies, fuel-efficient engines , and adaptable drive types.
Built in Suizhou, China’s “Special Purpose Vehicle Capital,” it leverages local industrial expertise: high-temperature heat dissipation systems, corrosion-resistant chassis, and easy maintenance. Backed by flexible customization and reliable after-sales support, it’s the trusted choice for businesses seeking cost-effective, climate-adapted logistics solutions.
Classification
1.Dry Van
- Purpose: Transports general dry goods (e.g., daily necessities, construction materials, packaged cargo) without temperature control.
- Key Feature: Standard fully enclosed compartment, the most widely used type in logistics.
2.Refrigerated/Insulated Van
- Purpose: Transports temperature-sensitive goods (e.g., fresh food, pharmaceuticals, frozen products).
- Sub-types:
- Insulated Van (ambient temperature preservation)
- Refrigerated Van (temperature range: -18°C to 5°C for cold chain transport)
3.Hazardous Materials Box Truck
- Purpose: Transports dangerous goods (e.g., flammable, explosive, corrosive substances).
- Key Feature: Compartment modified for explosion-proof/leak-proof, requiring compliance with regional safety certifications.
4.Medical Supply Van
- Purpose: Transports medical supplies (e.g., vaccines, medical equipment, sterile goods).
- Key Feature: Compartment equipped with disinfection systems, temperature control, and dust-proof seals.
5.Construction Material Box Truck (Wing Van)
- Purpose: Transports large/bulky construction materials (e.g., steel pipes, electrical appliances).
- Key Feature: Side “wing” doors that open upward for efficient loading/unloading.
6.Urban Distribution Van
- Purpose: Short-distance urban logistics (e.g., express delivery, community grocery distribution).
- Key Feature: Compact size, flexible maneuverability, suitable for narrow city roads.
Technical Datas:
| Parameter | Specification |
| Vehicle Type | 4.2m Light-duty Box Truck (Dry Van) |
| Drive Type | 4×2 |
| Gross Vehicle Weight | 4,495 kg |
| Rated Payload Capacity | 1,500–1,800 kg |
| Overall Dimensions (L×W×H) | 5,995 × 2,250 × 3,100 mm |
| Cargo Compartment Dimensions (L×W×H) | 4,200 × 2,100 × 2,100 mm |
| Cargo Volume | ~18–20 m³ |
| Engine Power | 120–160 HP (Yuchai/Weichai diesel engine, adapted for high-temperature environments) |
| Fuel Type | Diesel |
| Fuel Consumption | ~12–15 L/100 km |
| Tire Specification | 7.00R16 |
| Emission Standard | Euro 4 |
| Compartment Material | Cold-rolled steel |
