Dongfeng 4X2 6CBM Water Foam Fire Fighting Truck
Water Tank: 3000L – 15000L
Foam Tank: 500L – 2000L
Fire Pump Flow Rate: 30L/s–60L/s
Fire Pump Pressure: 1.0MPa–1.6MPa
Fire Monitor Water Range: ≥65m
Fire Monitor Foam Range: ≥55m
Chassis Drive Type: 4×2 / 4×4 / 6×4
Engine: 210HP–380HP
Category:Fire Truck
Introduction
Fire Truck also known as Fire Engine, Fire Rescue Truck, or Emergency Fire Vehicle, this specialized life-saving vehicle is engineered with a comprehensive suite of fire-fighting and rescue equipment—including a high-capacity water tank, high-pressure pump, extendable ladders, fire hoses, foam extinguishing systems, hydraulic rescue tools, cutting equipment, and emergency lighting. Designed to combat fires of all scales and perform critical rescue missions, it fulfills core functions: extinguishing structural fires, vehicle fires, wildland fires, and chemical blazes; rescuing people trapped in collapsed structures, elevated spaces, or flooded areas; and providing emergency support such as cutting through debris, stabilizing unstable structures, and supplying water in disaster zones.
Equipped with advanced safety features (reflective markings, sirens, thermal imaging cameras) and crew protection gear, it ensures operational safety for firefighters while delivering efficient emergency response. As an indispensable asset for municipal fire departments, industrial safety teams, and emergency services, it plays a critical role in protecting lives, property, and infrastructure.
Classification:
1. Tanker fire Trucks: These tanker fire vehicles are equipped with large water tanks that can hold hundreds or even thousands of gallons of water. Tanker fire trucks are used to transport and supply water to firefighting operations in areas where a water source may be limited or unavailable.
2. Pumper fireTrucks: Pumper fire trucks are equipped with pumps and hoses that allow firefighters to transfer water from a water source, such as a hydrant or natural body of water, to the scene of a fire. These trucks are essential for extinguishing fires in urban areas where a reliable water supply is readily accessible.
3. Aerial Platform Trucks: Aerial platform trucks, also known as ladder trucks, are equipped with a hydraulic platform or ladder that allows firefighters to reach tall buildings or structures to extinguish fires from above. These trucks are especially useful in densely populated areas with high-rise buildings.
4. Brush fire Trucks: Brush trucks are specially designed for fighting wildfires in rural or forested areas. These trucks are equipped with off-road capabilities and often carry water tanks, hoses, and equipment for creating firebreaks. Brush trucks are essential for quickly responding to and containing wildfires in remote locations.
Technical Datas:
| Dongfeng 4X2 Water Foam Fire Fighting Truck | |||
| Cab | Double cabin (four doors) | ||
| overall dimension | L*W*H | mm | 8530*2500*3500 |
| total mass(KG) | Kg | 18,750 | |
| Rated payload | Kg | 8,000 | |
| Kerb weight | Kg | 10,300 | |
| Approach/ departure angel | “ | 18/13 | |
| Front /rear suspension | mm | 1560/2177 | |
| Fuel type | diesel | Fuel consumption | 32 L/100km |
| Ground clearance | mm | 248 | |
| Max speed | Km/h | 90 | |
| Engine | Model/ rated power | Hp | Wd615.62 / 266 HP |
| Emission standard | Euro II or above | ||
| Rated speed | r/nin | 2200 | |
| Max. torque | 1100(N.m) / 1100~ 1600(rpm) | ||
| Displacement | ML | 9726 | |
| Driving type | 4*2 | Wheel base | 4600mm |
| Front tread | 1958mm | Rear tread | 1830mm |
| Front axle | 6500kg | Rear axle | 16000kg |
| Number of leaf spring of suspension | 9/9+6 | Type & size of tyre | 11.00-20 |
| Electrical system | Battery capacity (A .h) | 2*12V 135Ah | |
| Alternator capacity (A) | 28V 55A 1540W | ||
| Starter motor power (Kw) | 24V 7.5kw | ||
| Technical parameter of fire fighting body | |||
| Liquid tanker | Volume: total 4000L (among, water: 3000L; foam: 1000L) | ||
| Material:high quality carbon steel plate, anti-rust treatment inside. | |||
| Structure: welding, there is baffle plate inner | |||
| Equipment: 2 manholes, with speediness lock and turn on equipment, 2overflow mechanisms | |||
| Material of the tanker : stainless steel 304 | |||
| Fire fighting pump and pipeline system | Model of fire fighting pump: CB10/40 | ||
| Pressure: 1.0Mpa | |||
| Flux: 40L/s | |||
| Suction depth:≥7m | |||
| Suction time: ≤35s | |||
| Installing type: central or rear | |||
| Pipeline system: | |||
| Suction pipeline: there is 125mm water inlet, can sop natural water source and sop the water from liquid tanker | |||
| Water outlet pipeline: there is one middle pressure water outlet on every side, and gun pipeling with dia.≥80mm on the top of tanker | |||
| Discharge remaining water system: to protect pump and all ball valves | |||
