HOWO 4X2 2-Car Carrier Flatbed Truck
Drive Type: 4×2, 4×4, 6×4, 8×4
Gross Vehicle Weight: 10T – 16T
Rated Payload Capacity: 8T – 12T (Suitable for 2 sedans/SUVs or 1 sedan + 1 light truck)
Overall Dimensions: 7.5m × 2.5m × 3.2m – 9.6m × 2.55m × 3.5m
Flatbed Dimensions: 6.8m × 2.4m – 8.6m × 2.5m
Flatbed Tilt Angle: ≤12°
Engine Power: 160HP – 240HP
Tire Specification: 8.25R20 / 9.00R20
Category：Tow Truck
Introduction
2-Car Carrier Flatbed Truck also known as a Dual-Car Hauler or 2-Vehicle Flatbed Transporter, this Suizhou-manufactured vehicle is designed to safely carry 2 cars (sedans, SUVs, or light trucks) simultaneously. Its core function is to enable cost-effective vehicle logistics via a tiltable/telescopic flatbed, which simplifies loading/unloading—even on uneven roads.
Ideal for car dealership deliveries, used car transportation, and regional auto logistics, it offers key advantages: 8–12T payload capacity, high-temperature-adapted diesel engines, corrosion-resistant flatbed coating (for desert/marine environments), and customizable sizes (6.8–8.6m flatbeds). Backed by Suizhou’s mature special-purpose vehicle supply chain, it balances durability, efficiency, and affordability for cross-regional vehicle transport.
Classification
1.Tiltable 2-Car Carrier
Key Features: Hydraulically controlled tiltable flatbed with an integrated ramp, enabling easy loading/unloading of vehicles without additional equipment. As the mainstream model produced in Suizhou, it is optimized for uneven roads, ensuring stable operation on gravel or rural terrains.
Application: Ideal for small to medium-sized vehicle transportation (sedans, SUVs) in regions with underdeveloped infrastructure.
2.Telescopic 2-Car Carrier
Key Features: Equipped with a telescopic flatbed (extendable length range: 6.8m–8.6m) that can be adjusted to fit different vehicle sizes, such as long-wheelbase SUVs or light trucks. The high-strength steel structure maintains load-bearing capacity while offering flexibility.
Application: Suitable for mixed transportation of various vehicle types, meeting the diverse needs of car dealerships and logistics companies .
3.Foldable 2-Car Hauler
Key Features: Foldable side extensions on the flatbed, which can be expanded to increase the carrying width (up to 2.55m). The foldable design reduces the vehicle’s width during non-operational travel, improving maneuverability on narrow urban roads.
Application: Specialized for transporting wide-body vehicles or oversized sedans.
Technical Datas
| Parameter | Specification |
| Vehicle Type | 2-Car Carrier Flatbed Truck (Dual-Car Hauler) |
| Drive Type | 4×2 (Mainstream) / 6×2 (Heavy-Duty Option) |
| Gross Vehicle Weight (GVW) | 10T – 16T |
| Rated Payload Capacity | 8T – 12T (Suitable for 2 sedans/SUVs or 1 sedan + 1 light truck) |
| Overall Dimensions (L×W×H) | 7.5m × 2.5m × 3.2m – 9.6m × 2.55m × 3.5m |
| Flatbed Dimensions (L×W) | 6.8m × 2.4m – 8.6m × 2.5m (Tiltable & telescopic design) |
| Flatbed Tilt Angle | ≤12° (Facilitates vehicle loading/unloading on uneven roads) |
| Engine Power | 160HP – 240HP (Yuchai/Weichai Diesel Engine) |
| Fuel Type | Diesel |
| Fuel Consumption | 15L – 22L/100km |
| Tire Specification | 8.25R20 / 9.00R20 (10 tires + 2 spares, heavy-duty anti-puncture tread) |
| Loading/Unloading System | Hydraulic tilt + manual fixing straps (optional hydraulic fixing clamps) |
| Flatbed Material | High-strength carbon steel |
| Emission Standard | Euro 2 / Euro 4 (Customizable for export markets) |
| Applicable Scenarios | Car logistics, used car transportation, dealership vehicle delivery |
