4×2 RHD/LHD Freezer Truck Meat Fruit Fish Refrigerated Truck
Refrigerated Body Volume: 3CBM to 20CBM
Temperature Range: -25°C to +25°C
Insulation Thickness: 60mm to 200mm
Body Material: FRP / Aluminum / Stainless Steel
Engine Power: 110HP to 240HP
Door Configuration: Rear Double Doors / Side Door
Payload Capacity: 1T to 30T
Emission Standard: Euro 2/3/4/5/6
Category：Refrigerated Truck
Introduction
Refrigerated Truck — widely referred to as Reefer Truck, Cooling Truck, Cold Van Truck or Temperature-Controlled Truck. Manufactured in Suizhou, China’s leading hub for specialized vehicles with decades of engineering expertise, this truck is tailored for preserving perishables in harsh climates.
Ideal for transporting fruits, vegetables, dairy, meat, pharmaceuticals, and frozen goods, it excels in urban distribution, long-haul desert routes, and rural supply chains — from Dubai’s scorching heat to Kenya’s tropical landscapes. Equipped with a durable insulation system and adjustable temperature control (-20°C to +15°C), it ensures cargo freshness while withstanding dust, extreme temperatures, and rough terrain. Leveraging Suizhou’s mature supply chain and quality assurance, our refrigerated trucks offer reliable performance, fuel efficiency, and customizable capacities (3–20 CBM), making them a trusted solution for logistics, agriculture, and healthcare industries.
Advantage
● 30 years experience on refrigerated truck designing
● Build strict QC team to guarantee the quality
● 24 months long guarantee time assurance
● CKD, SKD parts service, Container shipping, Save freight
● Fast delivery time, Quick 10 days shipping time
Feature
Purpose: It is used for transporting frozen fish, meat, chicken, duck, fresh vegetable and vaccinum etc.
Manufactured by our company, best production craft, sandwich structure freezer box, good thermal insulation capacity
Very lig ht curb weight, fuel saving, and load more weight of cargoes
Truck box n ew craft, aluminum box edge reinforced, more strength
Optional refrige r ation unit: -15ºC~0ºC, -5ºC~0ºC, 0ºC~5ºC, not only cooling, we also have h eating unit
More options on c hassis a nd enigne, such as Foton, Dongfeng, Howo, isuzu, JMC, Shacman, etc.
Technical Datas
| Howo 4×2 freezer truck | ||
| General | ||
| Chassis Brand | Sinotruk HOWO | |
| Model | CEEC5040GXH | |
| Condition | New | |
| Overall Dimensions (L x W x H) | 5995×2350×3425mm | |
| GVW/Curb Weight | 4495/3210kg | |
| Front/Rear Track | 1610/ 1555mm | |
| Front /Rear Overhang | 1160/1555mm | |
| Max Speed | 95km/h | |
| Chassis | ||
| Cab | SINOTRUK HOWO Leader chassis, 2 seats,with A/C,USB,direction assistance | |
| Wheelbase | 3360mm | |
| Drive Type | 4X2,LHD | |
| Engine | Type | Inline 4-cylinder, direct injection, water-cooled, four-stroke, supercharged and intercooled, electronically controlled high-pressure common rail |
| Model | WEICHAI WP3NQ160E61 | |
| Horsepower | 160HP/ 118kW | |
| Rated Speed | 3000rpm | |
| Max Torque | 480N·m | |
| Fuel Type | Diesel,120L | |
| Displacement | 2.97L | |
| Emission Standard | Euro 6 | |
| Gearbox | Xingrui ML650A,6-speed,manual | |
| Tire | 7.50R16LT 8PR,6+1 | |
| Upper Structure | ||
| Box Dimensions (L x W x H) | 4100×2300×2050mm | |
| Material | Fiberglass material, FRP + PU foam + FRP 105 mm panel material, fully enclosed sandwich panel | |
| Door/floor | Right side door, full size double rear door, non-slip and wear-resistant floor | |
| Refrigeration unit | Model | CARRIER CITIMAX D6 |
| Type | Non-independent refrigeration unit | |
| Cooling capacity | 6000W(0/30℃) | |
| Air volume | 2200 m³/h | |
| Temperature Range | -20～40℃ | |
| Suitable for box volume(-20～40℃) | 23 m³ | |
| Voltage | 12/24V | |
| Road current consumption | 34/19A | |
| Application | Transport Freezer Food | |
